Model: SR3110
Dimensions (W x D x H): 800 (19 inch) x 1100 x 2000 mm
Packing Dimensions (W x D x H): 830 x 1160 x 2156 mm
Net Weight : 150 kg
Model: SR1110
Dimensions (W x D x H): 600 x 1100 x 2000 mm
Packing Dimensions (W x D x H): 630 x 1160 x 2156 mm
Net Weight: 137 kg
Model: SR3160
Dimensions (W x D x H): 800 x 1200 x 2000 mm
Packing Dimensions (W x D x H): 830 x 1260 x 2156 mm
Net Weight: 160 kg
Model: SR1160
Dimensions (W x D x H): 600 x 1200 x 2000 mm
Packing Dimensions (W x D x H): 630 x 1260 x 2156 mm
Net Weight: 150 kg
Environment
Operating Temperature: 0 to 40˚C
Operating Humidity: 0-95%
Altitude: 0-3000 m
Storage Temperature: -15 to 50˚C
Conformance
Ingress Protection: IP20
Rack Standards: EIA-310-D
Safe Grounding: UL 60950 (max. 63 A)
Sustainability: RoHS
Accessory List

P/N	Description	Rack Compatibility
P/N	Description	SR3110	SR1110	SR3160	SR1160
SR7001	1U Horizontal Cable Management Channel	●	●	●	●
SR7002	Vertical Cable Management Channel	●	●	●	●
SR7003	Cable Ladder, 300 mm	●	●	●	●
SR7004	Ring Type Wire Holder (10 pcs/per box)	●	●	●	●
SR8001	Power Cable Trough with Through-Hole, 800 mm	●		●
SR8002	Cable Trough with Through-Hole, 800 mm	●		●
SR8003	Bottom Cover for W800 x D1100 mm Rack Cabinet	●
SR9001	Power Cable Trough with Through-Hole, 600 mm		●		●
SR9002	Cable Trough with Through-Hole, 600 mm		●		●
SR9003	Bottom Cover for W600 x D1100 mm Rack Cabinet		●
SR9004	1U Fixed Shelf	●	●	●	●
SR9005	1U Sliding Shelf	●	●	●	●
SR9006	1U Blanking Panel (10 pcs/per box)	●	●	●	●
SR9007	2U Blanking Panel (10 pcs/per box)	●	●	●	●

These specifications are subject to change without notice. Please contact us or our distributors in your region for the latest specs.
